Blink and press
A circuit by romi lopez (@romi-lopez), shared on Mokxi. Open it and press Run: it runs in your browser, free.
Runs in your browser. Free · 1 remix · 1 heart.

The notes
There is no microcontroller in this one: the simulator solves the circuit itself.
sketch.ino
// Mokxi.
// This circuit has no board, so Run simulates the parts only.
// Add a board and pick a program in its Firmware panel: the editor then shows
// that program's source, and Run builds what you type here for that board.
void setup() {
pinMode(13, OUTPUT);
Serial.begin(115200);
}
void loop() {
digitalWrite(13, HIGH);
delay(500);
digitalWrite(13, LOW);
delay(500);
}
Parts list
6 parts, plus the jumper wires. Every one is in the editor's parts bin.
- 1 × Full-size breadboard
- 1 × Op-amp
- 1 × Oscilloscope
- 2 × Resistor
- 1 × Signal generator
