Community project · Arduino Uno R3
Carburetor synchronizer
By @707mjanes
A circuit on the Arduino Uno R3 by @707mjanes, shared on Mokxi. Open it and press Run: it runs in your browser, free.
Runs in your browser. Free · 1 heart.

The code
The sketch exactly as it was saved. Open it in the editor and press Run: it compiles in your browser.
CarbSync.ino · uno1
// Carburetorsynchronizer using an Arduino Uno
// it will need code to moniter at least two
// pressure sensors, 'smooth' the output so it's usable,
// then output that data to a screen.
//
//
//
//
//
void setup() {
pinMode(LED_BUILTIN, OUTPUT);
}
void loop() {
digitalWrite(LED_BUILTIN, HIGH);
delay(250);
digitalWrite(LED_BUILTIN, LOW);
delay(500);
}
sketch.ino
// Mokxi.
// This circuit has no board, so Run simulates the parts only.
// Add a board and pick a program in its Firmware panel: the editor then shows
// that program's source, and Run builds what you type here for that board.
void setup() {
pinMode(13, OUTPUT);
Serial.begin(115200);
}
void loop() {
digitalWrite(13, HIGH);
delay(500);
digitalWrite(13, LOW);
delay(500);
}
Parts list
5 parts, plus the jumper wires. Every one is in the editor's parts bin.
